People tell me all the time that they don't want to use Service Broker because it is too confusing. There are too many moving parts. What's the difference between a service and a queue? How do I monitor Service Broker? Where's the GUI? I started a blog series called Service Broker Demystified because SB really isn't that tough if you don't get lost in the weeds.
I was helping a customer with a new Service Broker implementation of my tickling pattern and I briefly said, "We'll worry about the Message Types and Contracts later...they really aren't required." The customer immediately stopped me and wanted to know why.
Many SB experts will disagree with me and state that contracts and message types are not optional...but they are. You don't need either for any Service Broker implementation. However, their use will help you avoid problems later. I consider contracts and message types to be the "foreign keys" and "check constraints" of the Service Broker world. You don't need FK and check constraints...but when you goof up your code you'll be glad you had them.
What is a Message Type?
When you send a message to a service by default it will have no message type. It's up to you, therefore, to "do the needful" with a given message. Maybe you have a tickler where the message is merely asking the target service to "wake up" and do something. In this case no message type is needed. However, for clarity I would still create a message type and call it Tickler with
VALIDATION = EMPTY...meaning I'm expecting it to have no payload.
Perhaps your service is simple enough that you only ever expect one type of message with a little bit of XML to traverse from service to service. You are fine with not validating your XML...you are a trusting soul. Again, no message type is really needed. But if you believe in "sanitizing your sql inputs" then you really do want to validate your XML. In that case, you need a message type that is either
WELL_FORMED_XML or, even better in most cases, VALID_XML with SCHEMA COLLECTION.
So, a message type is a lot like various constraints on a table.
|Type of "constraint"
||Message Type Equivalent
|no constraint on a NVARCHAR(MAX) column
||With NONE you can do whatever you want with the Message Type payload. Just like you can do just about anything with an NVARCHAR(MAX) column
|CHECK and DEFAULT on a bit column
||EMPTY means the message payload must not contain anything. This is kinda/sorta like a NOT NULL specification on a bit column with a DEFAULT of 1 and CHECK CONSTRAINT of 1. The column will be automatically set to the only possible value of 1. EMPTY is used to flag that an event occurred. The target service will have defined workflows that will respond to that event.
|a datatype declaration on a column
||When you declare a datatype on a column you are specifying that only certain valid data will be allowed. In this case only text that can be converted to the xml datatype will be accepted.
|CHECK constraint to enforce a mask on a SSN col
||VALID_XML WITH SCHEMA COLLECTION
||This states that the XML must be in a given format, much like a SSN is in the format "123-45-6789".
A CHECK constraint limits the allowable values in a column to a defined domain. A Message Type does the same thing for your XML message payloads. As with a CHECK constraint, a message type is not needed, but you'll find you have better quality data, and less support issues, when you have them properly implemented.
Whenever I design a new SB implementation I don't concern myself with the message types in the beginning. I want to get a prototype up and running quickly. After I have some stability I then add in these constraints.
What is a Contract?
A contract is a binding agreement between a message type and who can utilize it. If you don't have message types then you don't have contracts. Period. So again, I save contract implementation for a point in the project when I have a stable design.
Service Broker conversations are always dialogs (that's why the syntax is
BEGIN DIALOG CONVERSATION). A dialogue in the English language, according to google, is a conversation between two or more people. In SQL Server it is a little more strict...a dialog is EXACTLY two parties...an Initiator and a Target. You can model monologs in Service Broker just like in other messaging systems, but it requires some extra effort and I'll cover that in a future blog post. (If you can't wait for that post...for a monolog in SB you really need to have an activator on the initiator side that is ENDing CONVERSATION). Again, we'll cover this in a future post since it is confusing and most noobs model their SB implementations as a series of monolog workflows, not dialogs (just my opinion).
We got off subject...a contract merely says who can SEND the given message type. Let's say you have SB services called EmployeeSvc and AccountingSvc. Let's say you have a message type of ExpenseReportSubmission. The goal is to allow the EmployeeSvc to submit an expense report to the AccountingSvc. Let's model this as simply as possible with NO contracts or message types. You can follow along by downloading the repro script.
Here is the most basic setup...there are NO contracts or message types defined. The [DEFAULT] contract is specified and the "contract clause" is necessary whenever you want to create a Service capable of receiving messages. See my last post for some clarification on that bit of confusion. If we don't at least provide the [DEFAULT] contract we'll get this error in the sending queue:
<Description>Target service 'AccountingSvc' does not support contract 'DEFAULT'.</Description>
Note on Line 35 that our message payload is empty. That's fine because the [DEFAULT] contract on the receiving service is set to
VALIDATION=NONE. Hence we get no error and the message is properly enqueued in the AccountingQ with a NULL message_body.
Of course this design is silly...you certainly wouldn't want to allow NULL messages in an expense submission workflow...but you can when you don't properly declare your "constraints". You can send just about any message and the AccountingSvc will accept it without validating it. Here is an expense submission using simple text and note that it too does not fail.
At this point it would be the responsibility of whatever program or activator is processing the AccountingQ to perform any message validation and send any errors back to the sending service. But it's probably better design to implement those constraints as message types and contracts. We do that by creating a MESSAGE TYPE that specifies that we will only accept WLL_FORMED_XML. We can of course be even more precise, but this should be sufficient to illustrate the point. We then create a contract that specifies that our new message type can only be sent by the initiator. Finally we bind the contract to the existing service.
Let's run a little test. This time we are going to send some XML (Line 81) and ensure that our message made it to the target service. Note that the previous two messages, prior to us adding the "constraints" are still available to be processed.
Let's see what happens when we attempt to send some garbage now that we have proper "constraints"
What? That actually did succeed! Why? Because we did not specify the contract clause of the BEGIN DIALOG statement. Look around Line 97. The
ON CONTRACT statement is missing. Note that we did include that on Line 78 in the previous screenshot above.
So, you are probably asking yourself, even with a proper constraint at the target service we can still send garbage? What's the point of contracts and message types? With a database constraint the constraint is enforced regardless of whether you specifically ask it to be enforced (yes, I know you can disable a constraint and force it to go untrusted).
The problem is easily explainable. Although we bound a contract to our service we did not "unbind" the DEFAULT contract...so it is still valid. We can query the SSB metadata to prove this:
So, we need to specifically DROP the [DEFAULT] contract. Let's do that and retest.
So now the error is being thrown correctly and we can no longer use the [DEFAULT] contract.
Here's one place where the "constraint" analogy for contracts and message types breaks down. Note that the message did not ERROR for the sender, rather it was simply put in sender's Q as an error, as well as being noted as an error in sys.transmission_queue. This is another case where SSB confuses noobs. As long as your
BEGIN DIALOG syntax is correct you can always send a message without the sender seeing the error. Instead, the error causes the message to be retained in the sender's queue and
We covered a lot of ground today around Contracts and Message Types. Both can be confusing until you remember that they are optional Service Broker objects. Everything will work just fine without them, but will work better with them.
